Products: Wall Panels

Vulcan Steel Structures offers a variety of wall panel profiles designed to cover virtually any building type. They provide architectural flexibility and design choices to complement other forms of wall systems such as: masonry, pre-cast, Exterior Insulation and Finish Systems (EIFS) and tilt-up.

PBR Wall Panel

The PBR wall panel is ideal for commercial, industrial and agricultural applications. It is the most popular wall panel due to its strength, appearance and economic value.


Specifications
  • 36″-wide coverage
  • 1 1/4″-high ribs spaced 12″ on center
  • Available in 26 gauge and 24 gauge
  • Finishes are silicone polyester and Kynar
  • 20-year material warranty available

Reverse PBR Wall Panel

The reverse PBR wall panel is a semi-concealed fastener panel that provides an architectural appearance. The results are an emphasis on the face of the panel rather than the rib.


Specifications
  • 36″-wide coverage
  • 1 1/4″ inverted ribs spaced 12″ on center
  • Available in 26 gauge and 24 gauge
  • Finishes are silicone polyester and Kynar
  • 20-year material warranty available

Shadow Rib Wall Panel

The Shadow Rib wall panel features a totally concealed fastener system, which gives an outstanding aesthetic quality. The ribs of the wall panel project to the interior of the structure.


Specifications
  • 16″-wide coverage with 3″ of depth
  • Available in 24 gauge or 22 gauge
  • Two methods of attachment: angle clip or Fab-Lok fastener
  • 20-year material warranty available

Mesa Wall Panel

The Mesa wall panel is the perfect choice for economy and performance. A fluted profile makes it ideal for both exterior and interior wall and ceiling applications in various markets, including industrial and commercial. Available in sizes ranging from 3″ to 6″ thick.


Specifications
  • Panel thickness: 3”, 4”, 5” and 6”
  • Insulating values (R):** 24, 32, 41 and 49
  • Panel width: 45”
  • Panel length: 8’ minimum to 50’ maximum based on a 48’ flatbed trailer length (consult your sales representative for other available lengths)
  • Insulation material: CFC-free, foamed-in-place polyisocyanurate foam (2.1 to 2.5 PCF density)
  • Joint configuration: Monolithic single tongue-and-groove design
  • Metal facings: 26-gauge galvanized steel (22-gauge and 24-gauge galvanized steel also available; 26-gauge stainless steel available for interior use)
  • Coatings: Imperial White polyester (plastisol available)
  • Accessories: Fasteners, clips, sealants and brake-formed flashings

7.2 Panel

The 7.2 Panel is an excellent choice when it comes to commercial and industrial applications. This panel can be installed either vertically or horizontally.


Specifications
  • 36″-wide coverage
  • 1 1/2″ rib height, 7.2″ on center
  • Available in 24 gauge and 26 gauge
  • Finishes are Galvalume Plus, silicone polyester or Kynar
  • 20-year material warranty available

FW-120 Panel

The FW-120 panel provides a flat appearance utilizing a concealed fastener. It is used either vertically or horizontally for architectural, commercial and industrial applications.


Specifications
  • 12″-wide coverage
  • 1 1/2″-deep panel with smooth or two to three minor pencil ribs
  • Available in 24 gauge and 22 gauge
  • Finish is Kynar
  • 20-year material warranty available

AVP Panel

The AVP Panel features a “V” shape high-rib design with pencil ribs and utilizes semi-concealed fasteners. It provides an improved aesthetics to the building design.


Specifications
  • 36″– wide coverage
  • 1 1/8″ high ribs, 12″ on center
  • Available in 26 gauge and 24 gauge
  • Finishes are silicone polyester and Kynar
  • 20-year material warranty available
